Leo I

General specifications

Application: Bike and pedestrian paths, Parks, Residential, Urban lighting, Walkways
Product Type: Bollards
Mounting Type: Floor mounted
Indoor/Outdoor Light: Outdoor

Lighting specifications

Power(W): 18
CRI: 75
SDCM Initial And Working: 5
Lumen Maintenance Code: 9
Number of LEDs (pcs): 20
Average Lamp Life (H): 100000
Light Source: SMD LED

Optical specification

Optic: Symmetric

Electrical specification

Nominal Input Current 230 (A): 0.080
Nominal Voltage and Frequency: 230/50
Input Voltage and Frequency: 180-265/50-60
Led Module Operating Voltage (V): 30
Total Harmonic Distortion: ≤15%
Electrical Protection Class: I
Nominal Power Of Single Led: 1, 5W
Power factor: 0.95
Driver Type: Integrated Driver On/Off
Driver Mounting: Integrated

Mechanical Characteristics

Body Color: Grey(01), Black(02), White(03), Graphite Grey(04)
IP Rating: 65
Body Material: Aluminum - Iron
Body Coating: Electrostatic powder paint
Closing Screen: PolyCarbonate (PC)
Rated Ambient Temperature (°C): 25
Working Temperature Range (°C): -20 ~ +50
Maximum Allowed Humidity (%): 95
Rated Abrupt Failure Value (%): 15
