Atria is a post-top entirely designed with LED technology. Enhanced by a stylish design with advanced heat dissipating system, Atria is the perfect partner for outdoor lighting. Thanks to its particular shape, the product guarantees a complete cut-off, very low power consumption and high luminous efficiency. The range is available in colour temperatures from 3000K up to 6500K, plus - thanks to its mechanical characteristics and the fact that it does not use mercury material in the structure - Atria expresses a constant power consumption and light output in a wide range of supply voltage, resulting an extraordinarily environmentally friendly product.
Application: Bike and pedestrian paths, Urban lighting
Product Type: Top pole luminaires
Mounting Type: Pole mounted
Indoor/Outdoor Light: Outdoor
Led Modules: Mid modules
Power(W): 35
CRI: 75
SDCM Initial And Working: 5
Lumen Maintenance Code: 9
Number of LEDs (pcs): 48
verage Lamp Life (H): 100000
Light Source: SMD LED
Optic: Symmetric
Nominal Input Current 230 (A): 0.160
Nominal Voltage and Frequency: 230/50
Input Voltage and Frequency: 180-265/50-60
Led Module Operating Voltage (V): 48
Total Harmonic Distortion: ≤15%
Electrical Protection Class: I
Nominal Power Of Single Led: 1, 5W
Power factor: 0.95
Body Color: Grey(01), Black(02), White(03), Graphite Grey(04)
IP Rating: 65
Body Material: Aluminum die-cast
Body Coating: Electrostatic powder paint
Closing Screen: PolyCarbonate (PC)
Rated Ambient Temperature (°C): 25
Working Temperature Range (°C): -20 ~+50
Maximum Allowed Humidity (%): 95
Rated Abrupt Failure Value (%): 15
Pipe Holder Diameter (mm): Ø60
Weight (Kg): 3.5
Dimensions (mm): 386(L)X386(W)X137, 5(H)
Atria is available in four different finishes: Grey, Black, White and Graphite Grey.
The sinuous body of the product, made of die-cast aluminum, is painted with electrostatic powders which guarantee the fixture, in addition to an ingress protection value equal to IP65, also a fine finish typically for outdoor use.
The absence of solvents prevents the powder Coating from releasing organic compounds. The advantage concerns both the optimization of yield, with 99% compared to the optimistic 50% of traditional solvent-based paints, and the fundamental protection of the operator's health. The environmental impact of powder Coating is much lower, therefore it allows for savings in waste disposal costs.
