Overview


General specifications

Application: Urban lighting, Car parks, Sport facilities, Large areas
Product Type: Flood lights
Mounting Type: Surface mounted, Ceiling mounted, Wall mounted, Ceiling pendant
Indoor/Outdoor Light: Outdoor

Lighting specifications

Led Modules: High modules
Power(W): 900
Delivered Lumen (lm): 119000, 125000, 136000, 139000, 143000, 144000, 146000, 151000
System Luminous Efficiency (lm/W): 132, 138, 151, 154, 158, 160, 162, 167
CRI: 75
SDCM Initial And Working: 5
Color Temperature (°K): 3000, 4000, 5000, 6500
Lumen Maintenance Code: 9
Number of LEDs (pcs): 378, 1008
Average Lamp Life (H): 100000
Light Source: SMD LED

Optical specification

Optic: Symmetric 10°, Symmetric 30°, Symmetric 50°, Symmetric 80°

Electrical specification

Nominal Input Current 230 (A): 4.100
Nominal Voltage and Frequency: 230/50
Input Voltage and Frequency: 180-265/50-60
Led Module Operating Voltage (V): 48, 54
Electrical Protection Class: I
Nominal Power Of Single Led: 1.5W, 6W
Power factor: 0.95
Driver Type: Integrated Driver On/Off

Mechanical Characteristics

Body Color: Grey(01), Black(02), White(03), Graphite Grey(04)
IP Rating: 66
Body Material: Extruded Aluminium/Stainless Steel-Iron
Body Coating: Electrostatic powder paint
Closing Screen: Polycarbonate
Rated Ambient Temperature (°C): 25
Working Temperature Range (°C): -20 ~+50
Maximum Allowed Humidity (%): 95

Weight and dimensions


Weight (Kg): 35.5
Dimensions (mm): 434(L)x768(W)x535(H)
